DESICCATORS (CUBIC MODELS) – JEIOTECH

Brand:

Category: Tags: ,

Stackable unit design provides space efficiency in daily use. Transparent polycarbonate desiccators are designed for easy viewing of desiccant and vessels.



MODEL: SDC-30/30U, SDC-45/45U

FEATURES

  • Trang bị ẩm kế: Giúp theo dõi độ ẩm bên trong từ phía trước.

  • Ngăn kéo điều chỉnh độ cao: Phù hợp với hình dạng và kích thước vật lưu trữ.

  • Quan sát trong suốt: Thiết kế bằng polycarbonate chống vỡ, không ăn mòn, dễ vệ sinh.

  • Phiên bản chặn UV: Dành cho việc bảo quản mẫu nhạy cảm với ánh sáng.

  • Khay chứa chất hút ẩm: Bằng nhựa PP, đi kèm tiêu chuẩn, dễ sử dụng.

TECHNICAL SPECIFICATIONS

Model Clear type SDC-30 *) SDC-45 *)
UV protection type SDC-30U *) SDC-45U *)

Internal volume (L / cu ft)

35 / 1.2

50 / 1.8

Dimension

Internal (W×D×H, mm / inch)

322x367x302 / 12.7×14.4×11.9

322x367x422 / 12.7×14.4×16.6

Exterior (W×D×H, mm / inch)

360×410×326 / 14.1×16.1×12.8

360×410×447 / 14.1×16.1×17.6

Shelf (W×D×H, mm / inch)

279×354×3 / 11.0×13.9×0.1

279×354×3 / 11.0×13.9×0.1

Drawer (W×D×H, mm / inch)

279×346×45 / 11.0×13.6×1.8

279×346×45 / 11.0×13.6×1.8

Desiccant tray(W×D×H, mm / inch)

218×268×26 / 8.6×10.6×1.0

218×268×26 / 8.6×10.6×1.0

Net weight (kg / lbs)

4.9 / 10.8

6.2 / 13.7

Drawers

Quantity (Standard / max.)

2 / 4

3 / 6

Max. load per drawer ((kg / lbs)

5 / 11.0

5 / 11.0

Cat. No.

Clear type AAAD5011 AAAD5021
UV protection type AAAD5111 AAAD5121

*) The deviation of the fitted hygrometers will be between 10 and 20%. The measuring of accurate humidity percentage should be needed a extra equipment.
